Solis Single Phase Low Voltage 8kW Energy Storage Hybrid Inverter

#2: SOL-S6-EH1P8K-L-PLUS

Solis 8kW Data Sheet

Solis 8kW User Manual

Solis 8kW Warranty

Solis Product Compatibility

Solis 8kW Single Phase Low Voltage Energy Storage Hybrid Inverter

Notes

• This inverter does not include a DC cable for battery storage

• A Solis 1-phase Meter ACR10R 16DTE with 120A CT is not compatible with the S6 PLUS model

• A Solis 1-phase Eastron meter is required for full functionality

Overview

The Solis 8kW Single Phase Low Voltage Energy Storage Hybrid Inverter PLUS is designed for high-demand residential and commercial solar applications. With advanced energy management features, it delivers reliable backup power, peak shaving, and flexible connection options for lead-acid or lithium batteries. Ideal for modern grid-tied or off-grid systems, this inverter maximises self-consumption and protects your investment.

Key Features

• Built-in Backup Port with automatic UPS switching

• AI Optimised cloud-based, automated energy management assistant

• Supports up to 190A max charge/discharge current

• 200% DC oversizing capability for flexible solar array configuration

• Customisable charge/discharge times with 6 programmable settings

• 10-second 200% surge power backup for critical loads

• Generator compatibility with automatic On/Off control

• Flexible 1-phase or 3-phase parallel connection, supporting up to 48kW

• AC coupling to upgrade existing grid-connected systems

• Peak shaving control in both self-use and generator mode

• Compatible with lead-acid and lithium batteries with multiple protection features


Technical Specifications

• Supplier Part No: S6-EH1P8K-L-PLUS

• Weight: 22.2 kg

• Rated Power: 8,000 W

• Max DC Power: 16,000 W

• Max AC Power (5 min): 8,000 W

• Surge AC Power (1 sec): 8,001 W

• Max DC Current: 64 A

• DC Inputs: 8, with MC4 connectors included

• Min PPT Voltage: 90 V | Max PPT Voltage: 435 V

• DC Startup/Shutdown Voltage: 90 V

• Max Input Voltage: 500 V

• MPPT Quantity: 8

• Transformer: None

• Euro Efficiency: 96.5%

• Warranty: 5 years
