Solis Single Phase 5kW AC-Coupled Inverters

#2: SOL-S6-EA1P5K-L Storage Systems - Charger-Inverter

Solis S6 5kW  Data Sheet

Solis S6 5kW User Manual

Solis Product Compatibility

Solis S6 5kW Warranty

 5yr extended warranty available here

Solis Single Phase 5kW Low Voltage AC-Coupled Inverter | AI Optimised

The Solis 5kW Low Voltage AC-Coupled Inverter is designed for reliable, efficient home energy storage and solar integration. Perfect for single-phase installations, this inverter ensures safe, flexible, and high-performance operation with modern lithium-ion battery systems.

Solis Meter 1ph Eastron with external CT - SDM120CT recommended for accurate energy reading

---

Key Features

• High charge/discharge capacity: 125A / 6kW maximum rating.

• Flexible charging schedules: Supports 6 different battery charging and discharging times.

• Real-time battery monitoring: Keep track of battery health and performance.

• Remote upgrades: Easily update firmware via internet connectivity.

• Peak shaving support: Optimise energy use in self-use and generator modes.

• Low standby power: Minimises overall system energy consumption.

• Enhanced battery protection: Prolongs battery lifespan and ensures safe operation.

---

Specifications

• Rated Power: 5,000 W

• Weight: 24.5 kg

• Max Current: 40 A

• Number of Phases: Single-phase (1)

• Compatibility: Works with Solis Low Voltage AC-coupled battery systems
