Simplify your installation and unlock seamless whole-home backup with the advanced SolaX X1 IES Matebox G2. Designed specifically for the SolaX X1 IES single-phase energy storage system, the Matebox G2 combines intelligent cable management with an integrated Automatic Transfer Switch (ATS), helping installers reduce installation time while delivering reliable backup power functionality for homeowners.

The pre-configured internal wiring layout allows for a faster, cleaner, and more professional installation compared to traditional manual wiring methods. By integrating the ATS directly into the enclosure, the Matebox G2 enables automatic switchover during grid outages, ensuring the property continues to receive power from the battery storage system with minimal interruption.

Ideal for residential solar and battery storage installations, the Matebox G2 also provides organised load distribution while maintaining a compact, IP65-rated weather-resistant enclosure suitable for indoor or outdoor installation.

Key Features & Benefits

• Integrated Automatic Transfer Switch (ATS) for seamless whole-home backup
• Designed specifically for the SolaX X1 IES single-phase energy storage system
• Pre-configured internal wiring for quicker, cleaner installations
• Reduces installation complexity and labour time
• Supports full home backup during grid power outages
• Integrated power distribution for connected household loads
• Compact and professional installation solution
• Durable IP65-rated enclosure for indoor or outdoor use
• Ideal for residential solar battery storage systems

Technical Specifications

• Compatible System: SolaX X1 IES Single-Phase ESS
• Backup Function: Whole-home backup capability
• Transfer Type: Automatic Transfer Switch (ATS)
• Enclosure Rating: IP65
• Dimensions: 549mm × 360mm × 192mm
• Weight: 11kg

Why Choose the SolaX X1 IES Matebox G2?

The Matebox G2 has been developed to streamline modern solar and battery installations while improving overall system reliability. By combining essential wiring infrastructure with an integrated gateway and ATS functionality, installers can significantly reduce installation time while providing homeowners with dependable automatic backup power protection.

Whether you're installing a new SolaX X1 IES system or upgrading an existing setup, the Matebox G2 offers a professional, efficient, and future-ready energy management solution for residential properties.
