Solax X1 Hybrid 5.0kw + TP12.0kw complete kit

# 3: 4591#4905

Solax X1 Inverter Data Sheet

Solax X1 Battery Data Sheet

For a full list of SolaX products click here.

Product Overview

The Solax X1 Hybrid Kit is a 4th generation single-phase 5.0kW hybrid inverter paired with Solax’s high-performance Triple Power battery system. This all-in-one solution allows you to store excess solar energy for later use, optimise self-consumption, and provide backup power when needed.

Kit Options

Battery storage capacity can be selected based on your requirements: 3kWh, 6kWh, 9kWh, or 12kWh.

This Kit Includes

• 1 x SolaX X1 G4 Hybrid 5.0D Inverter

• 1 x SolaX Master Box for TP3.0 Battery

• 4 x SolaX Triple Power 3.0kWh HV Batteries

• 1 x Cable Kit

• 1 x SolaX Battery Base (required for 3 or more batteries)

Key Features

• IP65 Protection – suitable for indoor or outdoor installation

• Quick Installation – plug-and-play design for ease of setup

• High Cycle Life – over 6,000 charge/discharge cycles

• Safe Lithium Iron Phosphate (LiFePO4) Chemistry – ensures long-lasting and reliable performance

• Flexible battery configuration for scalable storage

• Provides backup power during outages

Specifications

• Inverter Rated Power: 5,000 W

• Battery Type: LiFePO4

• Battery Capacity Options: 3, 6, 9, 12kWh

• Protection Rating: IP65

• Installation: Wall-mounted or floor-standing with included base
