Fox H3 30kW 3-Phase Hybrid/AC Inverter – Expandable High-Performance Storage

The Fox H3 30kW Hybrid/AC Inverter is a powerful and scalable solution for residential, commercial, or industrial solar energy storage systems. With up to 30kW charge/discharge capability and support for multiple battery series, this inverter allows you to expand your storage capacity up to 86.4 kWh. A maximum of 10 inverters can be connected in parallel, giving you full flexibility to scale your system according to your energy needs.

---

Key Features:

• Plug-and-play installation – quick and easy to install

• IP65 rated – suitable for outdoor installations

• Remote monitoring via FoxESS Cloud for real-time system control

• Expandable battery capacity – compatible with multiple Fox HV and Cube battery series

• High voltage system – ensures maximum round-trip efficiency

• Supports 2 battery stacks per H3 model for larger storage configurations

---

Compatible Battery Series:

• 1x FE-HV-BMS + (3-16)x FE-HV-2600

• 1x ECM-2900 (Master) + (2-6)x ECS-2900 (Slave) (Connector Type A)

• 1x ECM-2900 (Master) + (2-6)x ECS-2900 (Slave) (Connector Type B)

• 1x ECM-4100 (Master) + (2-6)x ECS-4100 (Slave)

• 1x ECM-4300 (Master) + (2-6)x ECS-4300 (Slave)

• 1x ECM-4800 (Master) + (2-6)x ECS-4800 (Slave)

Maximum configuration: 2 stacks with 7 modules per stack (1 Master + 6 Slaves), totaling 2 Masters + 12 Slaves.

---

Technical Specifications:

• Weight: 57.5 kg

• Rated Power: 30,000 W

• DC Startup Voltage: 160 V | DC Shutdown Voltage: 1,000 V

• Max DC Input Voltage: 1,000 V | Max DC Power: 45,000 W

• Max AC Power (5 Minutes): 30,000 W | Surge AC Power (1 Second): 33,000 W

• Max DC Current: 96 A | DC Inputs: 6 | DC Fuses: 1

• Connector Type: MC4 | Included Connectors: 6

• MPPT Quantity: 3 | Euro Efficiency: 97.4%

• Transformer: None | Integrated DC Switch: Yes

• Warranty: 5 years

• Certifications: G99 and G100

---

This inverter is perfect for high-demand solar installations, offering scalable battery integration, advanced monitoring, and industry-leading efficiency.
