Dyness DL5.0C Pro 5.12kWh LV LFP Battery  (indoor only) Heating Element

#2: DY-DL5.0C-PRO

Dyness DL5 Pro 5.12kWh Datasheet

Dyness DL5 Pro 5.12kWh User Manual

Dyness Compatibility List

Dyness DL5  5.12kWh Warranty

To view complete Dyness full range please visit our Dyness main page

Dyness Pro stackable brackets available here

The Dyness DL5.0C Pro is a high-performance 5.12kWh lithium battery storage system designed for reliable residential energy storage. Built with advanced lithium-ion technology, this compact and efficient battery helps homeowners store surplus solar energy for use when they need it most, reducing reliance on the grid and improving energy independence.

Ideal for domestic solar and battery storage systems, the Dyness DL5.0C Pro combines strong performance, flexible scalability, and intelligent temperature management in a sleek wall-mounted or floor-standing design.

Key Features

5.12kWh Usable Battery Storage

The Dyness DL5.0C Pro offers 5.12kWh nominal energy capacity, making it well suited for storing excess solar generation for evening and overnight use. It is an excellent option for homeowners looking to improve self-consumption and reduce electricity bills.

Expandable System Design

This battery supports up to 50 units in parallel, allowing for substantial system expansion where higher storage capacity is required. Whether for a small domestic setup or a larger energy storage installation, the DL5.0C Pro offers impressive scalability.

1C Discharge Performance

With 1C discharge capability, the Dyness DL5.0C Pro delivers strong output performance for demanding household loads. This makes it suitable for homes that require dependable battery discharge for high-consumption periods.

Integrated Heating Function

The built-in heating function supports battery operation in colder conditions, helping maintain reliable performance across a wide operating temperature range. It can charge and discharge in temperatures from -20°C to 50°C, making it a practical solution for varied installation environments.

Long-Life Lithium-Ion Technology

Using advanced lithium-ion battery chemistry, the Dyness DL5.0C Pro delivers dependable long-term performance, high efficiency, and excellent depth of discharge to maximise usable stored energy.

Compact and Practical Design

With a weight of 46kg, the Dyness DL5.0C Pro offers a compact and manageable storage solution for residential battery installations while maintaining robust performance.

Technical Specifications

Battery Performance

• Nominal Energy: 5.12kWh

• Battery Type: Lithium-Ion

• Nominal Voltage: 51V

• Operating Voltage Range: 44.7V – 57.6V

• Depth of Discharge: 90%

• Discharge Rate: 1C

Power Output

• Continuous Discharge Rate: 5632W

• Maximum Discharge Rate (5 Minutes): 3840W

• Surge Discharge Rate (15 Seconds): 5632W

• Maximum Charge Rate (5 Minutes): 3840W

Environmental & Physical Details

• IP Rating: IP20

• Operating Temperature: -20°C to 50°C

• Heating Function: Yes

• Weight: 46kg

Important Compatibility Information

Please note that the Dyness DL5.0C Pro is not compatible with the Dyness DL5.0C. These two battery models must not be mixed within the same battery system.

Why Choose the Dyness DL5.0C Pro?

The Dyness DL5.0C Pro is a strong choice for homeowners and installers looking for a reliable solar battery storage solution with flexible expansion, solid discharge performance, and dependable year-round operation. Its combination of 5.12kWh storage capacity, parallel scalability, and integrated heating makes it a versatile option for modern residential energy systems.

Whether you are upgrading an existing solar battery setup or installing a new energy storage system, the Dyness DL5.0C Pro offers the performance and flexibility needed for efficient home energy management.

---

Regulatory Requirement (UK)

In accordance with PAS regulations, this battery requires a battery disconnector, such as: KETO-00-80A Battery Isolator
