Duracell Home Battery Dura-i 6kW Hybrid Inverter PD-DH1P-6-G1

#5: Duracell Energy Dura-i 6kW Hybrid Inverter PD-DH1P-6-G1

Duracell Inverter Data Sheet

Duracell Inverter Manual



Duracell Energy Dura-i 6kW Hybrid Inverter – Reliable Solar Power Conversion

The Duracell Energy Dura-i 6kW Hybrid Inverter (PD-DH1P-6-G1) is designed to maximise your solar energy system’s efficiency while offering the flexibility of hybrid functionality. Built with Duracell’s reputation for reliability and innovation, this inverter delivers powerful performance and easy integration with modern solar and battery storage solutions.

Perfect for residential and small commercial systems, it combines high efficiency, modular scalability, and smart connectivity, making it a future-ready choice for sustainable energy.

---

Key Features

• Hybrid & AC Compatible – Works with both new and existing solar setups.

• High Efficiency – Up to 97.3% PV to AC and 94.3% Battery to AC conversion.

• Integrated Energy Meter – Smart monitoring for accurate energy management.

• Scalable Design – Connect up to 6 inverters in parallel for larger systems.

• Battery Compatibility – Designed to integrate seamlessly with the Duracell Dura5 battery.

• Flexible Warranty Options – 5-year standard warranty, extendable to 10 years.

---

Technical Specifications

• Model: PD-DH1P-6-G1

• AC Output Power: 6,000 VA

• Max PV Power: 9,000 W

• Max PV Voltage: 550 V

• MPPT Trackers: 2 (1 string per MPPT)

• Max Charge/Discharge Current: 120 A

• Max Charge/Discharge Power: 6,000 W

• Efficiency:

  • PV to AC: 97.3%

  • Battery to AC: 94.3%

• Output Current: 27.2 A

• Rated Voltage: 230 V

• Weight: 25 kg

• Dimensions: 585 × 485 × 175 mm

• Operating Temperature: -25°C to +60°C

• Installation: Wall-mounted

• Display: LED

• Communication Ports: CAN / RS485
